LU5D FREUD Saw blades to cut non-ferrous metals and plastics

Code: LU5D

Price from: 32,10 €

Saw blades to cut non-ferrous metals and plastics
Machines: Double head cutting machines, mitre saws.
Materials: Aluminium, copper, brass, plastics and PVC.
Applications: Aluminium, non-ferrous metals and plastics cutting.
Technical information: To cut drawn products and tubes whose thickness does not exceed 3 mm. It is recommended to use it on cutting machines where the saw blade is over the workpiece to be cut. Suitable for PVC profiles cutting.

Measures

Quantity discounts

FT02: 2/9/46,2 + 2/10/60

Code	D (mm)diameter	B (mm)cutting height	bbody thickness	dhole diameter	Zteeth	FT / CHdrive holes	PriceVAT not inc.	PriceVAT inc. not for companies	Quantity
LU5D 0100	D (mm): 160	B (mm): 2,8	b: 2,2	d: 20	Z: 42	KN (CH): –	36,94€	45,07€	LU5D 0100 quantity
LU5D 0200	D (mm): 190	B (mm): 2,8	b: 2,2	d: 30	Z: 54	KN (CH):	45,14€	55,07€	LU5D 0200 quantity
LU5D 0300	D (mm): 200	B (mm): 2,8	b: 2,2	d: 30	Z: 60	KN (CH):	48,56€	59,24€	LU5D 0300 quantity
LU5D 0400	D (mm): 210	B (mm): 2,8	b: 2,2	d: 30	Z: 60	KN (CH):	48,56€	59,24€	LU5D 0400 quantity
LU5D 0500	D (mm): 216	B (mm): 2,8	b: 2,2	d: 30	Z: 60	KN (CH):	51,64€	63,00€	LU5D 0500 quantity
LU5D 0600	D (mm): 220	B (mm): 3,0	b: 2,5	d: 30	Z: 64	KN (CH): FT02	55,40€	67,59€	LU5D 0600 quantity
LU5D 0700	D (mm): 230	B (mm): 3,0	b: 2,5	d: 30	Z: 64	KN (CH):	56,09€	68,43€	LU5D 0700 quantity
LU5D 0800	D (mm): 250	B (mm): 3,5	b: 3,0	d: 30	Z: 80	KN (CH): FT02	70,45€	85,95€	LU5D 0800 quantity
LU5D 0900	D (mm): 250	B (mm): 3,5	b: 3,0	d: 32	Z: 80	KN (CH): 2/11/63	70,45€	85,95€	LU5D 0900 quantity
LU5D 1000	D (mm): 250	B (mm): 3,5	b: 3,0	d: 40	Z: 80	KN (CH): 2/9/55+4/12/64	70,45€	85,95€	LU5D 1000 quantity
LU5D 1100	D (mm): 275	B (mm): 3,5	b: 3,0	d: 40	Z: 84	KN (CH): 2/9/55+4/12/64	77,98€	95,14€	LU5D 1100 quantity
LU5D 1200	D (mm): 300	B (mm): 3,5	b: 3,0	d: 30	Z: 96	KN (CH): FT02	86,18€	105,14€	LU5D 1200 quantity
LU5D 1300	D (mm): 300	B (mm): 3,5	b: 3,0	d: 32	Z: 96	KN (CH): 2/11/63	86,18€	105,14€	LU5D 1300 quantity
LU5D 1400	D (mm): 300	B (mm): 3,5	b: 3,0	d: 40	Z: 96	KN (CH): 2/9/55+4/12/64	86,18€	105,14€	LU5D 1400 quantity
LU5D 1500	D (mm): 330	B (mm): 3,5	b: 3,0	d: 30	Z: 104	KN (CH): FT02	97,13€	118,50€	LU5D 1500 quantity
LU5D 1600	D (mm): 330	B (mm): 3,5	b: 3,0	d: 32	Z: 104	KN (CH): 2/11/63	97,13€	118,50€	LU5D 1600 quantity
LU5D 1700	D (mm): 350	B (mm): 3,5	b: 3,0	d: 30	Z: 108	KN (CH): FT02	99,52€	121,41€	LU5D 1700 quantity
LU5D 1800	D (mm): 350	B (mm): 3,5	b: 3,0	d: 32	Z: 108	KN (CH): 2/11/63	99,52€	121,41€	LU5D 1800 quantity
LU5D 1900	D (mm): 350	B (mm): 3,5	b: 3,0	d: 40	Z: 108	KN (CH): 2/9/55+4/12/64	99,52€	121,41€	LU5D 1900 quantity
LU5D 2000	D (mm): 370	B (mm): 3,5	b: 3,0	d: 30	Z: 108	KN (CH):	107,39€	131,02€	LU5D 2000 quantity
LU5D 2200	D (mm): 380	B (mm): 3,5	b: 3,0	d: 32	Z: 108	KN (CH): 2/11/63	107,39€	131,02€	LU5D 2200 quantity
LU5D 2300	D (mm): 400	B (mm): 3,5	b: 3,0	d: 30	Z: 120	KN (CH):	111,49€	136,02€	LU5D 2300 quantity
LU5D 2400	D (mm): 400	B (mm): 3,5	b: 3,0	d: 32	Z: 120	KN (CH): 2/11/63	111,49€	136,02€	LU5D 2400 quantity
LU5D 2500	D (mm): 400	B (mm): 3,5	b: 3,0	d: 40	Z: 120	KN (CH): 2/15/80+2/12/64	111,49€	136,02€	LU5D 2500 quantity
LU5D 2600	D (mm): 400	B (mm): 3,5	b: 3,0	d: 50	Z: 120	KN (CH): 4/15/80	111,49€	136,02€	LU5D 2600 quantity
LU5D 2700	D (mm): 420	B (mm): 4,0	b: 3,2	d: 30	Z: 120	KN (CH): 2/11/70	162,11€	197,77€	LU5D 2700 quantity
LU5D 2800	D (mm): 420	B (mm): 4,0	b: 3,2	d: 40	Z: 120	KN (CH):	162,11€	197,77€	LU5D 2800 quantity
LU5D 2900	D (mm): 450	B (mm): 4,0	b: 3,2	d: 30	Z: 128	KN (CH):	166,90€	203,62€	LU5D 2900 quantity
LU5D 3400	D (mm): 500	B (mm): 4,0	b: 3,2	d: 32	Z: 140	KN (CH): 2/11/63	190,84€	232,82€	LU5D 3400 quantity
